Tapered cutting for single-use molding
Focusing on laser groove cutting and processing Can achieve full width ± 45° groove cutting Multiple grooves single-shaping, stable cutting, high efficiency
Intelligent and efficient bus system
Intelligent bus control system Fast response, high precision and fast data transfer Realization of highly intelligent and flexible cutting
The new design of the double dragon bone bed
In response to the needs of thick sheet processing, self-developed double keel design with insertion stop Thick sheet cutting without deformation,
ensuring long-term stable operation of the equipment
New type of combustion protection and thermal insulation technology
Utilizes a new type of flame retardant, anti-burn and thermal insulation technology Ensures cutting accuracy and extends the life of the equipment
Technical Parameter
mm
inch
Model
 FB3015 FB6020
Laser power
8000W-30000W 8000W-30000W
Working Area
6100*2050mm 3100*1550mm
Accuracy Of Positioning
±0.03mm ±0.03mm
Repositioning Accuracy
±0.02mm ±0.02mm
Maximum Acceleration
1.2G 1.2G
Model
 FB3015 FB6020
Laser power
8000W-30000W 8000W-30000W
Working Area
240*80inch 122*61inch
Accuracy Of Positioning
±0.0011811 inch ±0.0011811 inch
Repositioning Accuracy
±0.0007874 inch ±0.0007874 inch
Maximum Acceleration
1.2G 1.2G
Cutting Sample
Contact us
If you are looking for partners, visiting us or want to join us, you can send a message directly to contact us.
