Mastery of all types of tubes
Wide range of cutting applications, suitable for different cutting conditions. Can intercept or cut complex shapes for different types of pipes.
Cutting of solid pipes and machining of tail material
The third chuck can grasp and pull the pipe material to achieve no residue when cutting the whole pipe.
Follow-up support to ensure safety and effectiveness
The loading and unloading areas are equipped with tracking supports to support the pipes in real time, which ensures cutting stability and improves cutting accuracy.
New double dragon bone bed construction.
With horizontal bed structure and proprietary double keel design with stop and insert, the center of gravity is low, the bearing capacity is great, and the cutting is more stable.
Technical Parameter
mm
inch
Model
 TS12035 TS12020 TS6020
Laser Output Power
1000W~6000W 1000W~6000W 1000W~6000W
Diameter Of Round Tube
φ15-350mm φ15-230mm φ15-230mm
Side length Of Square Tube
□15-350mm □15-230mm □15-230mm
Positioning Accuracy
±0.05mm ±0.05mm ±0.05mm
Repeat Positioning Accuracy
±0.05mm ±0.05mm ±0.05mm
Maximum Speed Of Movement
80m/min 110m/min 110m/min
Maximum Acceleration
0.8G 1.5G 1.5G
Model
 TS12035 TS12020 TS6020
Laser Output Power
1000W~6000W 1000W~6000W 1000W~6000W
Diameter Of Round Tube
φ0.59inch-0.866inch φ13.77-9.05inch φ13.77-9.05inch
Side length Of Square Tube
□0.59-0.866inch □13.77-9.05inch □13.77-9.05inch
Positioning Accuracy
±0.00197inch ±0.00197inch ±0.00197inch
Repeat Positioning Accuracy
±0.00197inch ±0.00197inch ±0.00197inch
Maximum Speed Of Movement
80m/min 110m/min 110m/min
Maximum Acceleration
0.8G 1.5G 1.5G
